Siemens SINUMERIK 808D

37012 FIXED_STOP_TORQUE_RAMP_TIME A10 -
s Time period until reaching the changed torque limit DOUBLE NEW CONF
-
808d-me42 - 0.0 0.0 - ReadOnly M
808d-me62 - 0.0 0.0 - ReadOnly M
808d-te42 - 0.0 0.0 - ReadOnly M
808d-te62 - 0.0 0.0 - ReadOnly M
808d-mte40 - 0.0 0.0 - 7/2 M
808d-mte60 - 0.0 0.0 - 7/2 M
Description: Period in seconds until the changed torque limit is reached.
The value 0.0 deactivates the ramp function.
37014 FIXED_STOP_TORQUE_FACTOR A10 TE3
- Adaption factor torque limit DOUBLE NEW CONF
-
808d-me42 - 1.0 0.0 - ReadOnly M
808d-me62 - 1.0 0.0 - ReadOnly M
808d-te42 - 1.0 0.0 - ReadOnly M
808d-te62 - 1.0 0.0 - ReadOnly M
808d-mte40 - 1.0 0.0 - 7/2 M
808d-mte60 - 1.0 0.0 - 7/2 M
Description: Interface factor torque limit.
With this factor, the torque limit of linked slave axes (MD 37250) can be weighted
additionally.
Even with different motors, the torque limits can be kept equal in all linked axes.
37020 FIXED_STOP_WINDOW_DEF A05, A10 -
mm, degrees Default fixed-stop monitoring window DOUBLE PowerOn
CTEQ
808d-me42 - 1.0 0.0 1.0e15 ReadOnly M
808d-me62 - 1.0 0.0 1.0e15 ReadOnly M
808d-te42 - 1.0 0.0 1.0e15 ReadOnly M
808d-te62 - 1.0 0.0 1.0e15 ReadOnly M
808d-mte40 - 1.0 0.0 1.0e15 7/2 M
808d-mte60 - 1.0 0.0 1.0e15 7/2 M
Description: This machine data is used to enter the default for the standstill monitoring window at
fixed stop.
Fixed stop monitoring becomes active as soon as the fixed stop is reached, i.e. NC/PLC
interface signal DB390x DBX2.5 (Fixed stop reached) is set.
If the position at which the fixed stop is detected is left by more than the tolerance
specified
in MD37020
$MA_FIXED_STOP_WINDOW_DEF alarm 20093 "Fixed stop monitoring has
responded" is output and the "FXS" function is deselected.
The value entered is a default setting and is active only as long as
● no fixed stop monitoring window is programmed with command FXSW[x],
● the fixed stop monitoring window is not changed via SD 43520: FIXED_STOP_WINDOW
(after reaching of fixed stop).
Related to:
SD43520 $SA_FIXED_STOP_WINDOW (fixed stop monitoring window)
Machine data
3.4 Axis-specific machine data
