37030 FIXED_STOP_THRESHOLD A10 -
mm, degrees Threshold for fixed stop detection DOUBLE NEW CONF
-
808d-me42 - 2.0 0.0 1.0e15 ReadOnly M
808d-me62 - 2.0 0.0 1.0e15 ReadOnly M
808d-te42 - 2.0 0.0 1.0e15 ReadOnly M
808d-te62 - 2.0 0.0 1.0e15 ReadOnly M
808d-mte40 - 2.0 0.0 1.0e15 7/2 M
808d-mte60 - 2.0 0.0 1.0e15 7/2 M
Description: Threshold value for fixed stop detection.
The contour deviation is checked for this threshold as a criterion for reaching the
fixed stop. Waiting until the set torque limit is reached is a further condition for
digital drives.
This machine data is only active if MD37040 $MA_FIXED_STOP_BY_SENSOR = 0.
The NC/PLC interface signal DB390x DBX2.5 (Fixed stop reached) is set if the axial
contour
deviation exceeds the threshold value set in MD37030 $MA_FIXED_STOP_THRESHOLD.
MD irrelevant to:
MD37040 $MA_FIXED_STOP_BY_SENSOR = 1
Related to:
NC/PLC interface signal DB390x DBX2.5 (Fixed stop reached)
37040 FIXED_STOP_BY_SENSOR A10 -
- Fixed stop detection by sensor BYTE Immediately
CTEQ
808d-me42 - 0 0 3 ReadOnly M
808d-me62 - 0 0 3 ReadOnly M
808d-te42 - 0 0 3 ReadOnly M
808d-te62 - 0 0 3 ReadOnly M
808d-mte40 - 0 0 3 7/2 M
808d-mte60 - 0 0 3 7/2 M
Description: This machine data defines how the criterion "Fixed stop reached" is determined.
A change of this machine data becomes active with the next selection of travel to fixed
stop.
MD=0
The criterion "Fixed stop reached" is determined internally on the basis of the axial
FIXED_STOP_THRESHOLD.
MD=1
The criterion "Fixed stop reached" is determined via an external sensor and signalled
to the NC via the NC/PLC interface signal DB380x DBX1.2 (Sensor fixed stop).
MD=2
The criterion "Fixed stop reached" is accepted if either the contour monitoring (MD =
0) or the signal of the external sensor (MD = 1) has responded.
MD=3
Triggering through movement analysis (only as an alternative to triggering via sensor)
Related to:
MD37030 $MA_FIXED_STOP_THRESHOLD
(threshold for fixed stop detection)
NC/PLC interface signal DB380x DBX1.2 (Sensor fixed stop)
