37050 FIXED_STOP_ALARM_MASK A05, A10 -
- Enable of the fixed stop alarms BYTE NEW CONF
-
808d-me42 - 1 0 31 ReadOnly M
808d-me62 - 1 0 31 ReadOnly M
808d-te42 - 1 0 31 ReadOnly M
808d-te62 - 1 0 31 ReadOnly M
808d-mte40 - 1 0 31 7/2 M
808d-mte60 - 1 0 31 7/2 M
Description: This machine data defines whether the alarms
20091 "Fixed stop not reached",
20094 "Fixed stop canceled" and
25042 "FOC: Standstill monitoring" are output.
MD= 0
Suppression of alarm 20091 "Fixed stop not reached"
MD= 2
Suppression of alarms
20091 "Fixed stop not reached" and
20094 "Fixed stop canceled" (SW 4 and higher)
MD=3
Suppression of alarm 20094 "Fixed stop canceled" (SW 4 and higher)
Add value 8
Suppression of alarm 25042 "FOC: Standstill monitoring" (SW 7 and higher)
Add value 16
Trigger alarm 20095 only if the brake test torque is less than the holding torque
Errors occurring during travel to fixed stop can be read out from the status variable
$AA_FXS irrespective of the setting of the alarm screen.
Standard: 1 = Alarms 20091, 20094 and 25042 are triggered
37052 FIXED_STOP_ALARM_REACTION A05, A10 -
- Reaction with fixed stop alarms BYTE PowerOn
-
808d-me42 - 0 0 - ReadOnly M
808d-me62 - 0 0 - ReadOnly M
808d-te42 - 0 0 - ReadOnly M
808d-te62 - 0 0 - ReadOnly M
808d-mte40 - 0 0 - 7/1 M
808d-mte60 - 0 0 - 7/1 M
Description: Behavior of VDI signal "Mode group ready" in case of fixed stop alarms:
Bit value = 0: "Mode group ready" will be deleted (drives de-energized)
Bit value = 1: "Mode group ready" remains active
Bit0: Alarm 20090 Travel to fixed stop not possible
Bit1: Alarm 20091 Fixed stop not reached
Bit2: Alarm 20092 Travel to fixed stop still active
Bit3: Alarm 20093 Standstill monitoring at fixed stop has triggered
Bit4: Alarm 20094 Travel to fixed stop canceled
All other bits without meaning.
Standard: 0 = All alarms de-energize the drives
Machine data
3.4 Axis-specific machine data
