Siemens SINUMERIK 808D

37060 FIXED_STOP_ACKN_MASK A10 -
- Waiting for PLC acknowledgments during travel to fixed stop BYTE PowerOn
CTEQ
808d-me42 - 0x0 0x0 0x3 ReadOnly M
808d-me62 - 0x0 0x0 0x3 ReadOnly M
808d-te42 - 0x0 0x0 0x3 ReadOnly M
808d-te62 - 0x0 0x0 0x3 ReadOnly M
808d-mte40 - 0x0 0x0 0x3 7/2 M
808d-mte60 - 0x0 0x0 0x3 7/2 M
Description: This machine data defines whether or not the NC waits for acknowledgment messages from
the PLC when the "Travel to fixed stop" function is active.
Bit 0 = 0
Once the NC has transmitted the interface signal DB390x DBX2.4 (Activate travel to
fixed stop) to the PLC, it starts the programmed traversing.
Bit 0 = 1
After the NC has transmitted the interface signal DB390x DBX2.4 (Activate travel to
fixed
stop) to
the PLC, it waits for the PLC to acknowledge with the interface signal
DB380x DBX3.1 (Enable travel to fixed stop) and then starts the programmed traversing.
Bit 0 = 1 should be set for analog drives so that the motion is not started before the
PLC has limited the torque in the drive.
Bit 1 = 0
Once the NC has transmitted the interface signal DB390x DBX2.5 (Fixed stop reached) to
the PLC, the program advances to the next block.
Bit 1 = 1
After the NC has transmitted the interface signal DB390x DBX2.5 (Fixed stop reached)
to
the PLC,
it waits for the PLC to acknowledge with the interface signal DB380x DBX1.1
(Acknowledge fixed stop reached), outputs the programmed torque and then advances to
the next block.
Bit 1 should be set for analog drives so that the PLC can switch the drive to torque-
controlled operation if a programmable clamping torque has to be specified.
With digital drives (PROFIdrive), the "Travel to fixed stop" function can be executed
without any acknowledgments, thus allowing program run times to be reduced.
Related to:
NC/PLC interface signal DB390x DBX2.4 (Activate travel to fixed stop)
NC/PLC interface signal DB380x DBX3.1 (Enable travel to fixed stop)
NC/PLC interface signal DB390x DBX2.5 (Fixed stop reached)
NC/PLC interface signal DB380x DBX1.1 (Acknowledge fixed stop reached)
37070 FIXED_STOP_ANA_TORQUE A10 -
% Torque limit when approaching the fixed stop for analog drives DOUBLE PowerOn
CTEQ
808d-me42 - 5.0 0.0 100.0 ReadOnly M
808d-me62 - 5.0 0.0 100.0 ReadOnly M
808d-te42 - 5.0 0.0 100.0 ReadOnly M
808d-te62 - 5.0 0.0 100.0 ReadOnly M
808d-mte40 - 5.0 0.0 100.0 7/2 M
808d-mte60 - 5.0 0.0 100.0 7/2 M
Description: Only for analog drives (not relevant for PROFIdrive digital drives):
Machine data
3.4 Axis-specific machine data
Parameter Manual
List Manual, 01/2017 313
