41050 JOG_CONT_MODE_LEVELTRIGGRD - H1
- Jog mode / continuous operation with continuous JOG BOOLEAN Immediately
-
808d-me42 - TRUE 0 - 1/1 M
808d-me62 - TRUE 0 - 1/1 M
808d-te42 - TRUE 0 - 1/1 M
808d-te62 - TRUE 0 - 1/1 M
808d-mte40 - TRUE 0 - 7/7 U
808d-mte60 - TRUE 0 - 7/7 U
Description: 1: Jog mode for JOG continuous
In jog mode (default setting) the axis traverses as long as the traverse key is held
down and an
axis limitation has not been reached. When the key is released the axis is
decelerated to zero speed and the movement is considered complete.
0: Continuous operation for JOG continuous
In continuous operation the traverse movement is started with the first rising edge of
the
traverse key
and continues to move even after the key is released. The axis can be
stopped again by pressing the traverse key again (second rising edge).
SD irrelevant for ......
Incremental jogging (JOG INC)
Reference point approach (JOG REF)
41100 JOG_REV_IS_ACTIVE - -
- JOG mode: revolutional feedrate / linear feedrate BYTE Immediately
-
808d-me42 - 0x0E 0 - 1/1 M
808d-me62 - 0x0E 0 - 1/1 M
808d-te42 - 0x0E 0 - 1/1 M
808d-te62 - 0x0E 0 - 1/1 M
808d-mte40 - 0x0E 0 - 7/7 U
808d-mte60 - 0x0E 0 - 7/7 U
Description: Bit 0 = 0:
The behavior depends on the following:
- in the case of an axis/spindle:
on the axial SD43300 $SA_ASSIGN_FEED_PER_REV_SOURCE
- in the case of a geometry axis with an active frame with rotation:
on the channel-specific SD42600 $SC_JOG_FEED_PER_REV_SOURCE
- in the case of an orientation axis:
on the channel-specific SD42600 $SC_JOG_FEED_PER_REV_SOURCE
Bit 0 = 1:
A JOG motion with revolutional feedrate shall be traversed depending on the master
spindle.
The following must be considered:
- If a spindle is the master spindle itself, it will be traversed without revolutional
feedrate.
- If the master spindle is in stop position and if SD43300
$SA_ASSIGN_FEED_PER_REV_SOURCE (with an axis/spindle) or SD42600
$SC_JOG_FEED_PER_REV_SOURCE
(with a
geometry axis with an active frame with rotation,
or with an orientation axis) = -3, traversing will be carried out without revolutional
feedrate.
Bit 1 = 0:
NC setting data
Parameter Manual
322 List Manual, 01/2017
