The axis/spindle, geometry axis or orientation axis will be traversed with
revolutional feedrate even during rapid traverse (see bit 0 for selection).
Bit 1 = 1:
The axis/spindle, geometry axis or orientation axis is always traversed without
revolutional feedback during rapid traverse.
Bit 2 = 0:
The axis/spindle, geometry axis or orientation axis is traversed with revolutional
feedrate during JOG handwheel travel, too (see bit 0 for selection).
Bit 2 = 1:
The axis/spindle, geometry axis or orientation axis is always traversed without
revolutional feedrate during JOG handwheel travel.
Bit 3 = 0:
The axis/spindle is traversed with revolutional feedrate during DRF handwheel travel,
too (see bit 0 for selection).
Bit 3 = 1:
The axis/spindle is always traversed without revolutional feedrate during DRF
handwheel travel.
41110 JOG_SET_VELO - H1
mm/min Axis velocity in JOG DOUBLE Immediately
-
- - 0.0 0.0 - 7/7 U
Description: Value not equal to 0:
The velocity value entered applies to linear axes traversed in JOG mode if linear
feedrate (G94) is active for the relevant axis (SD41100 $SN_JOG_REV_IS_ACTIVE = 0).
The axis velocity is active for
● continuous jogging
● incremental jogging (INC1, ... INCvar)
● handwheel traversing.
The value entered is valid for all linear axes and must not exceed the maximum
permissible axis velocity (MD32000 $MA_MAX_AX_VELO).
In the case of DRF, the velocity defined by SD41110 $SN_JOG_SET_VELO is reduced by
MD32090 $MA_HANDWH_VELO_OVERLAY_FACTOR.
Value = 0:
If 0 has been entered in the setting data, the active linear feedrate in JOG mode is
MD32020 $MA_JOG_VELO "Jog axis velocity". Each axis can be given its own JOG velocity
with this MD (axial MD).
SD irrelevant for ......
● Linear axes if SD41100 $SN_JOG_REV_IS_ACTIVE = 1
● Rotary axes (SD41130 $SN_JOG_ROT_AX_SET_VELO is active here)
Application example(s)
The operator can thus define a JOG velocity for a specific application.
Related to ....
SD41100 $SN_JOG_REV_IS_ACTIVE (revolutional feedrate with JOG active)
Axial MD32020 $MA_JOG_VELO (JOG axis velocity)
Axial MD32000 $MA_MAX_AX_VELO (maximum axis velocity)
Axial MD32090 $MA_HANDWH_VELO_OVERLAY_FACTOR (ratio of JOG velocity to handwheel
velocity (DRF))
SD41130 $SN_JOG_ROT_AX_SET_VELO (JOG speed with rotary axes)
NC setting data
Parameter Manual
List Manual, 01/2017 323
