Siemens SINUMERIK 808D Parameter Manual

41120 JOG_REV_SET_VELO - H1
mm/rev Revolutional feedrate of axes in JOG mode DOUBLE Immediately
-
808d-me42 - 0.0 0.0 - 1/1 M
808d-me62 - 0.0 0.0 - 1/1 M
808d-te42 - 0.0 0.0 - 1/1 M
808d-te62 - 0.0 0.0 - 1/1 M
808d-mte40 - 0.0 0.0 - 7/7 U
808d-mte60 - 0.0 0.0 - 7/7 U
Description: Value not equal to 0:
The velocity value entered applies to axes traversed in JOG mode if revolutional
feedrate (G95) is active for the relevant axis (SD41100 $SN_JOG_REV_IS_ACTIVE = 1).
The axis velocity is active for
● continuous jogging
● incremental jogging (INC1, ... INCvar)
● handwheel traversing. The value entered is valid for all axes and must not exceed
the maximum permissible axis velocity (MD32000 $MA_MAX_AX_VELO).
Value = 0:
If 0 has been entered in the setting data, the active revolutional feedrate in JOG mode
is MD32050 $MA_JOG_REV_VELO "revolutional feedrate with JOG".
Each axis can be given its own revolutional feedrate with this MD (axial MD).
SD irrelevant for ......
● For axes if SD41100 $SN_JOG_REV_IS_ACTIVE = 0
Application example(s)
The operator can define a JOG velocity for a particular application.
Related to ....
Axial SD41100 $SN_JOG_REV_IS_ACTIVE (revolutional feedrate for JOG active)
Axial MD32050 $MA_JOG_REV_VELO (revolutional feedrate with JOG)
Axial MD32000 $MA_MAX_AX_VELO (maximum axis velocity)
41130 JOG_ROT_AX_SET_VELO - H1
rev/min Axis velocity for rotary axes in JOG mode DOUBLE Immediately
-
- - 0.0 0.0 - 7/7 U
Description: Value not equal to 0:
The velocity entered applies to rotary axes in JOG mode (to continuous jogging,
incremental jogging, jogging with handwheel). The value entered is common to all
rotary axes, and must not exceed the maximum permissible axis velocity (MD32000
$MA_MAX_AX_VELO).
With DRF, the velocity set with SD41130 $SN_JOG_ROT_AX_SET_VELO must be reduced by
MD32090 $MA_HANDWH_VELO_OVERLAY_FACTOR.
Value equal to 0:
If the value 0 is entered in the setting data, the velocity applied to rotary axes in
JOG mode is the axial MD32020 $MA_JOG_VELO (jog axis velocity). In this way, it is
possible to define a separate JOG velocity for each axis.
Application example(s)
The operator can define a JOG velocity for a particular application.
Related to ....
MD32020 $MA_JOG_VELO (JOG axis velocity)
MD32000 $MA_MAX_AX_VELO (maximum axis velocity)
NC setting data
Parameter Manual
324 List Manual, 01/2017
