MD32090 $MA_HANDWH_VELO_OVERLAY_FACTOR (ratio JOG velocity to handwheel velocity (DRF)
41200 JOG_SPIND_SET_VELO - H1
rev/min Speed for spindle JOG mode DOUBLE Immediately
-
- - 0.0 0.0 - 7/7 U
Description: Value not equal to 0:
The speed entered applies to spindles in JOG mode if they are traversed manually by
the "Plus and minus traversing keys" or the handwheel. The speed is active for
● continuous jogging
● incremental jogging (INC1, ... INCvar)
● handwheel traversing. The value entered is valid for all spindles, and must not
exceed the maximum permissible speed (MD32000 $MA_MAX_AX_VELO).
Value = 0:
If 0 has been entered in the setting data, MD32020 $MA_JOG_VELO (JOG axis velocity)
acts as the JOG velocity. Each axis can thus be given its own JOG velocity with this
MD (axial MD).
The maximum speeds of the active gear stage (MD35130 $MA_GEAR_STEP_MAX_VELO_LIMIT) are
taken into account when traversing the spindle with JOG.
SD irrelevant for ......
Application example(s). The operator can thus define a JOG speed for the spindles for
a specific application.
Related to ....
Axial MD32020 $MA_JOG_VELO (JOG axis velocity)
MD35130 $MA_GEAR_STEP_MAX_VELO_LIMIT (maximum speeds of the gear stages)
41300 CEC_TABLE_ENABLE - K3
- Compensation table enable BOOLEAN Immediately
-
808d-me42 6 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-me62 8 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-te42 6 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-te62 8 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1 M
808d-mte40 6 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
808d-mte60 8 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7 U
Description: 1: The evaluation of the compensation table [t] is enabled.
NC setting data
Parameter Manual
List Manual, 01/2017 325
