42100 DRY_RUN_FEED - V1
mm/min Dry run feedrate DOUBLE Immediately
-
- - 5000., 5000., 5000.,
5000., 5000., 5000.,
5000., 5000....
0.0 - 7/7 U
Description: The feedrate for the active dry run is entered in this setting data. The setting data
can be altered on the operator panel in the "Parameters" operating area.
The entered dry run feedrate is always interpreted as a linear feed (G94). If the dry
run feedrate is activated via the PLC interface, the dry run feedrate is used as the
path
feed after
a reset instead of the programmed feed. The programmed velocity is used
for traversing if it is greater than the velocity stored here.
Application example(s)
Program testing
Related to ....
NC/PLC interface signal DB3200 DBX0.6 (Activate dry run feedrate)
NC/PLC interface signal DB1700 DBX0.6 (Dry run feedrate selected)
42101 DRY_RUN_FEED_MODE - V1
- Mode for dry run velocity BYTE Immediately
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 12 7/7 U
Description: This SD can be used to set the method of operation of the dry run velocity set by
SD42100 $SC_DRY_RUN_FEED.
The following values are possible:
0:
The maximum of SD42100 $SC_DRY_RUN_FEED and the programmed velocity become active.
This is the standard setting and corresponds to the behavior up to SW 5.
1:
The minimum of SD42100 $SC_DRY_RUN_FEED and the programmed velocity become active.
2:
SD42100 $SC_DRY_RUN_FEED becomes active directly, irrespective of the programmed
velocity.
The values 3...9 are reserved for extensions.
10:
As configuration 0, except for thread cutting (G33, G34, G35) and tapping (G331, G332,
G63). These functions are executed as programmed.
11:
As configuration 1, except for thread cutting (G33, G34, G35) and tapping (G331, G332,
G63). These functions are executed as programmed.
12:
As configuration 2, except for thread cutting (G33, G34, G35) and tapping (G331, G332,
G63). These functions are executed as programmed.
42110 DEFAULT_FEED - V1, FBFA
mm/min Path feed default value DOUBLE Immediately
-
- - 0., 0., 0., 0., 0., 0., 0.,
0....
0.0 - 7/7 U
NC setting data
Parameter Manual
List Manual, 01/2017 329
