42984 CUTDIRMOD C08 -
- Modification of $P_AD[2] or $P_AD[11] STRING Immediately
-
808d-me42 - - - - 0/0 S
808d-me62 - - - - 0/0 S
808d-te42 - - - - 0/0 S
808d-te62 - - - - 0/0 S
808d-mte40 - - - - 7/7 U
808d-mte60 - - - - 7/7 U
Description: States whether the tool point direction and cutting direction are to be modified on
reading the corresponding system variables $P_AD[2] and $P_AD[11].
Modification is made by rotating the vector of the tool point direction or cutting
direction by a specific angle in the active machining plane (G17-G19). The resulting
output value is always the tool point direction or cutting direction created by the
rotation or to
which the rotated value is closest. the angle of rotation can be defined
by one of the following six options:
1: The string is empty. The stated data are output unchanged.
2: The contents of the string is "P_TOTFRAME". The resulting rotation is determined
from the total frame.
3: The contents of the string is a valid frame name (e.g. $P_NCBFRAME[3]). The
resulting rotation is then calculated from this frame.
4: The contents of the string has the form "Frame1 : Frame2". The resulting rotation
is determined from the part frame chain that is created by chaining all frames from
Frame1
to
Frame2
(in each case inclusive). Frame1 and Frame2 are valid frame names such
as $P_PFRAME or $P_CHBFRAME[5]"
5: The contents of the frame is the valid name of a rotary axis (machine axis). The
resulting rotation is
determined from the programmed end position of this rotary axis.
Additionally, an offset can be stated (in degrees, e.g. "A+90).
6: The rotation is programmed explicitly (in degrees).
Optionally, the first character of the string can be written as sign (+ or -). A plus
sign will not have any effect on the angle calculation, but a minus sign will invert
the sign of the calculated angle.
42990 MAX_BLOCKS_IN_IPOBUFFER - K1
- Maximum number of blocks in IPO buffer DWORD Immediately
-
808d-me42 - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 1/1 M
808d-me62 - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 1/1 M
808d-te42 - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 1/1 M
808d-te62 - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 1/1 M
808d-mte40 - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 7/7 U
808d-mte60 - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 7/7 U
NC setting data
