42995 CONE_ANGLE - -
- Taper angle DOUBLE Immediately
-
808d-me42 - - -90 90 7/7 U
808d-me62 - - -90 90 7/7 U
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... -359.9 359.9 7/7 U
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... -359.9 359.9 7/7 U
808d-mte40 - - -90 90 7/7 U
808d-mte60 - - -90 90 7/7 U
Description: This setting data writes the taper angle for taper turning. This setting data is
written via the operator interface.
42996 JOG_GEOAX_MODE_MASK - -
- JOG of geometry axis mode DWORD Immediately
-
808d-me42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 2/2 M
808d-me62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 2/2 M
808d-te42 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 2/2 M
808d-te62 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 2/2 M
808d-mte40 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 7/7 U
808d-mte60 - 0, 0, 0, 0, 0, 0, 0, 0... 0 0x7 7/7 U
Description: This setting data sets the following during JOG of geometry axes:
Bit 0 = 1 :
A traversing request for the 1st geometry axis is inverted, i.e. a traversing request
to + triggers a traversing motion to - .
Bit 1 = 1 :
A traversing request for the 2nd geometry axis is inverted, i.e. a traversing request
to + triggers a traversing motion to -.
Bit 2 = 1:
A traversing request for the 3rd geometry axis is inverted, i.e. a traversing request
to + triggers a traversing motion to -.
43120 DEFAULT_SCALE_FACTOR_AXIS - FBFA
- Axial default scaling factor with G51 active DWORD Immediately
-
- - 1 - - 2/2 M
Description: If no axial scaling factor I, J, or K is programmed in the G51 block, SD43120
$SA_DEFAULT_SCALE_FACTOR_AXIS is active.
The scaling factor is only active if MD22914
$MC_AXES_SCALE_ENABLE is set.
Related to:
MD22914 $MC_AXES_SCALE_ENABLE,
MD22910 $MC_WEIGHTING_FACTOR_FOR_SCALE
43200 SPIND_S - S1
rev/min Speed for spindle start by VDI DOUBLE Immediately
-
- - 0.0 0.0 - 7/7 U
NC setting data
Parameter Manual
362 List Manual, 01/2017
