Description: Spindle speed at spindle start by NC/PLC interface signals DB380x DBX5006.1 (Spindle
start clockwise rotation) and DB380x DBX5006.2 (Spindle start counterclockwise
rotation).
Example: SD43200 $SA_SPIND_S[S1] = 600
Spindle 1 is started at a speed of 600 rpm upon detection of the positive edge of one
of the above-mentioned VDI starting signals.
Speed programming values are entered in the SD by setting bit 4=1 in MD35035
$MA_SPIND_FUNCTION_MASK.
The SD becomes active in JOG mode as a default speed by setting bit 5=1 in MD35035
$MA_SPIND_FUNCTION_MASK (exception: the value is zero).
Related to:
MD35035 $MA_SPIND_FUNCTION_MASK
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43202 SPIND_CONSTCUT_S - S1
m/min Const cut speed for spindle start by VDI DOUBLE Immediately
-
- - 0.0 0.0 - 7/7 U
Description: Definition of the constant cutting speed for the master spindle.
The setting data is evaluated at spindle start by the NC/PLC interface signals DB380x
DBX5006.1 (Spindle start clockwise rotation) and DB380x DBX5006.2 (Spindle start
counterclockwise rotation)
Cutting speed programming values are entered in the SD by setting bit 8=1 in MD35035
$MA_SPIND_FUNCTION_MASK.
Related to:
MD35035 $MA_SPIND_FUNCTION_MASK
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43206 SPIND_SPEED_TYPE A06 -
- Spindle speed type for spindle start through VDI DWORD Immediately
-
- - 94 93 973 7/7 U
Description: Definition of the spindle speed type for the master spindle.
The range of values and the functionality correspond to the 15th G group "feed type".
Permissible values are the G values: 93, 94, 95, 96, 961, 97, 971 and 973.
The stated values make a functional distinction between the following variants:
==> 93, 94, 95, 97 and 971: The spindle is started at the speed in SD 43200
$SA_SPIND_S.
==> 96 and 961: The speed of the spindle is derived from the cutting speed of SD
43202 $SA_SPIND_CONSTCUT_S and the radius of the transverse axis.
==> 973: G973 behaves like G97, but the spindle speed limitation is not active
The default value is 94 (corresponds to G94)
The default value becomes active if the SD is written with impermissible values.
43210 SPIND_MIN_VELO_G25 - S1
rev/min Programmed spindle speed limitation G25 DOUBLE Immediately
-
- - 0.0 0.0 - 7/7 U
NC setting data
Parameter Manual
List Manual, 01/2017 363
