Description: The working area defined in the basic coordinate system in the positive direction of
the axis concerned can be limited with axial working area limitation.
The setting data can be changed on the operator panel in the operating area
"Parameters".
The positive working area limitation can be changed in the program with G26.
SD irrelevant for ......
G code: WALIMOF
Related to ....
SD43400 $SA_WORKAREA_PLUS_ENABLE
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43430 WORKAREA_LIMIT_MINUS - A3
mm, degrees Working area limitation minus DOUBLE Immediately
-
- - -1.0e+8 - - 7/7 U
Description: The working area defined in the basic coordinate system in the negative direction of
the axis concerned can be limited with axial working area limitation.
The setting data can be changed on the operator panel in the operating area
"Parameters".
The negative working area limitation can be changed in the program with G25.
SD irrelevant for ......
G code: WALIMOF
Related to ....
SD43410 $SA_WORKAREA_MINUS_ENABLE
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43700 OSCILL_REVERSE_POS1 - P5
mm, degrees Oscillation reversal point 1 DOUBLE Immediately
-
808d-me42 - 0.0 - - 7/7 U
808d-me62 - 0.0 - - 7/7 U
808d-te42 - 0.0 - - 0/0 S
808d-te62 - 0.0 - - 0/0 S
808d-mte40 - 0.0 - - 7/7 U
808d-mte60 - 0.0 - - 7/7 U
Description: Position of the oscillating axis at reversal point 1.
Note:
MD10710 $MN_PROG_SD_RESET_SAVE_TAB can be be set so that the value written by the part
program is transferred to the active file system on reset (that is the value is
retained after RESET.)
Application example(s)
NC language: OSP1[Axis]=Position
Related to ....
SD43710 $SA_OSCILL_REVERSE_POS2
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
NC setting data
Parameter Manual
List Manual, 01/2017 367
