SD42600 $SC_JOG_FEED_PER_REV_SOURCE (revolutional feedrate for geometry axes on
which a frame with rotation acts in JOG mode.)
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43320 JOG_POSITION - -
mm, degrees JOG position DOUBLE Immediately
-
- - 0.0 - - 7/7 U
Description: Position to be approached in JOG. Depending on MD10735 $MN_JOG_MODE_MASK bit 4 axial
frames and, with an axis configured as geometry axis, the tool length offset are
considered.
43340 EXTERN_REF_POSITION_G30_1 , A12 FBFA
- Reference point position for G30.1 DOUBLE Immediately
-
- - 0.0 - - 7/7 U
Description: Reference point position for G30.1.
This setting data will be evaluated in CYCLE328.
43400 WORKAREA_PLUS_ENABLE - A3
- Working area limitation active in positive direction BOOLEAN Immediately
CTEQ
- - FALSE 0 - 7/7 U
Description: 1: The working area limitation of the axis concerned is active in the positive
direction.
0: The working area limitation of the axis concerned is switched off in the positive
direction.
The setting data is parameterized via the operator panel in the operating area
"Parameters" by activating/deactivating the working area limitation.
SD irrelevant for ......
G code: WALIMOF
43410 WORKAREA_MINUS_ENABLE - A3
- Working area limitation active in the negative direction BOOLEAN Immediately
CTEQ
- - FALSE 0 - 7/7 U
Description: 1: The working area limitation of the axis concerned is active in the negative
direction.
0: The working area limitation of the axis concerned is switched off in the negative
direction.
The setting data is parameterized via the operator panel in the operating area
"Parameters" by activating/deactivating the working area limitation.
SD irrelevant for ......
G code: WALIMOF
43420 WORKAREA_LIMIT_PLUS - A3
mm, degrees Working area limitation plus DOUBLE Immediately
-
- - 1.0e+8 - - 7/7 U
