808d-te62 - 0.0 - - 0/0 S
808d-mte40 - 0.0 - - 7/7 U
808d-mte60 - 0.0 - - 7/7 U
Description: Hold time of the oscillating axis at reversal point 2.
Note:
MD 10710 $MN_PROG_SD_RESET_SAVE_TAB can be be set so that the value written by the part
program is transferred to the active file system on reset (that is the value is
retained after reset.)
Application example(s)
NC language: OST2[Axis]=Position
Related to ....
SD43720 $SA_OSCILL_DWELL_TIME1
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43740 OSCILL_VELO - P5
mm/min, rev/min Feedrate of reciprocating axis DOUBLE Immediately
-
808d-me42 - 0.0 0.0 - 7/7 U
808d-me62 - 0.0 0.0 - 7/7 U
808d-te42 - 0.0 0.0 - 0/0 S
808d-te62 - 0.0 0.0 - 0/0 S
808d-mte40 - 0.0 0.0 - 7/7 U
808d-mte60 - 0.0 0.0 - 7/7 U
Description: Feed rate of the oscillating axis
Note:
MD 10710 $MN_PROG_SD_RESET_SAVE_TAB can be be set so that the value written by the part
program is transferred to the active file system on reset (that is the value is
retained after reset.)
Application example(s)
NC language: FA[Axis]=F value
Related to ....
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43750 OSCILL_NUM_SPARK_CYCLES - P5
- Number of spark-out strokes DWORD Immediately
-
808d-me42 - 0 0.0 - 7/7 U
808d-me62 - 0 0.0 - 7/7 U
808d-te42 - 0 0.0 - 0/0 S
808d-te62 - 0 0.0 - 0/0 S
808d-mte40 - 0 0.0 - 7/7 U
808d-mte60 - 0 0.0 - 7/7 U
Description: Number of sparking-out strokes performed after ending the oscillating movement
Application example(s)
NC language: OSNSC[Axis]=Stroke number
Note:
NC setting data
Parameter Manual
List Manual, 01/2017 369
