MD 10710 $MN_PROG_SD_RESET_SAVE_TAB can be be set so that the value written by the part
program is transferred to the active file system on reset (that is the value is
retained after reset.)
Related to ....
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43760 OSCILL_END_POS - P5
mm, degrees End position of the reciprocating axis DOUBLE Immediately
-
808d-me42 - 0.0 - - 7/7 U
808d-me62 - 0.0 - - 7/7 U
808d-te42 - 0.0 - - 0/0 S
808d-te62 - 0.0 - - 0/0 S
808d-mte40 - 0.0 - - 7/7 U
808d-mte60 - 0.0 - - 7/7 U
Description: Position the oscillating axis travels to after ending the sparking-out strokes.
Note:
MD 10710 $MN_PROG_SD_RESET_SAVE_TAB can be be set so that the value written by the part
program is transferred to the active file system on reset (that is the value is
retained after reset.)
Application example(s)
NC language: OSE[Axis]=Position
Related to ....
MD10709 $MN_PROG_SD_POWERON_INIT_TAB
MD10710 $MN_PROG_SD_RESET_SAVE_TAB
43770 OSCILL_CTRL_MASK - P5
- Oscillation sequence control mask DWORD Immediately
-
808d-me42 - 0 0 0x7FFFFFFF 7/7 U
808d-me62 - 0 0 0x7FFFFFFF 7/7 U
808d-te42 - 0 0 0x7FFFFFFF 0/0 S
808d-te62 - 0 0 0x7FFFFFFF 0/0 S
808d-mte40 - 0 0 0x7FFFFFFF 7/7 U
808d-mte60 - 0 0 0x7FFFFFFF 7/7 U
Description: Bit mask:
Bit no. | Meaning in OSCILL_CTRL_MASK
------------------------------------------------------------------------------
0(LSB)-1 | 0: Stop at the next reversal point if the
| oscillating movement is switched off
|
| 1: Stop at reversal point 1 if the
| oscillating movement is switched off
| 2: Stop at reversal point 2 if the
| oscillating movement is switched off
| 3: Do not approach a reversal point when the oscillating movement is
switched off
| if no sparking-out strokes are programmed
------------------------------------------------------------------------------
NC setting data
Parameter Manual
370 List Manual, 01/2017
