Description: In the case of position-dependent temperature compensation, the error curve
characteristic of the temperature-dependent actual-value deviation can often be
approximated by a straight line. This straight line is defined by a reference point
P_0 and a slope tan-ß.
SD43910 $SA_TEMP_COMP_SLOPE defines the slope tan-ß. This slope can be changed by the
PLC user program as a function of the current temperature.
The axis traverses additionally the compensation value calculated for the current
actual position as soon as the position-dependent temperature compensation becomes
active (MD32750 $MA_TEMP_COMP_TYPE = = 2 or 3).
MD32760 $MA_COMP_ADD_VELO_FACTOR limits the maximum angle of slope tan-ß_max of the
error curve. This maximum angle of slope cannot be exceeded.
SD irrelevant for ......
MD32750 $MA_TEMP_COMP_TYPE = 0 or 1
Special cases, errors, ......
When SD43910 $SA_TEMP_COMP_SLOPE is greater than tan-ß_max, the slope tan-ß_max is
used
to calculate
the position-dependent temperature compensation value internally. No
alarm is output.
Related to ....
MD32750 $MA_TEMP_COMP_TYPE Temperature compensation type
SD43920 $SA_TEMP_COMP_REF_POSITION Reference position for position-dependent
temperature compensation
MD32760 $MA_COMP_ADD_VELO_FACTOR Velocity overshoot caused by compensation
43920 TEMP_COMP_REF_POSITION - K3
- Ref. position of position-dependent temperature compensation DOUBLE Immediately
-
808d-me42 - 0.0 - - ReadOnly M
808d-me62 - 0.0 - - ReadOnly M
808d-te42 - 0.0 - - ReadOnly M
808d-te62 - 0.0 - - ReadOnly M
808d-mte40 - 0.0 - - 7/7 U
808d-mte60 - 0.0 - - 7/7 U
Description: In the case of position-dependent temperature compensation, the error curve
characteristic of the temperature-dependent actual-value deviation can often be
approximated by a straight line. This straight line is defined by a reference point
P_0 and a slope tan-ß.
SD43920 $SA_TEMP_COMP_REF_POSITION defines the position of the reference point P_0.
This reference position can be changed by the PLC user program as a function of the
current temperature.
The axis traverses additionally the compensation value calculated for the current
actual position as soon as the position-dependent temperature compensation becomes
active (MD32750 $MA_TEMP_COMP_TYPE = 2 or 3).
SD irrelevant for ......
MD32750 $MA_TEMP_COMP_TYPE = 0 or 1
Related to ....
MD32750 $MA_TEMP_COMP_TYPE Temperature compensation type
SD43910 $SA_TEMP_COMP_SLOPE Angle of slope for position-dependent temperature
compensation
NC setting data
Parameter Manual
List Manual, 01/2017 373
