43790 OSCILL_START_POS - -
mm, degrees Start position of reciprocating axis DOUBLE Immediately
-
808d-me42 - 0.0 - - 7/7 U
808d-me62 - 0.0 - - 7/7 U
808d-te42 - 0.0 - - 0/0 S
808d-te62 - 0.0 - - 0/0 S
808d-mte40 - 0.0 - - 7/7 U
808d-mte60 - 0.0 - - 7/7 U
Description: Position approached by the oscillating axis at the start of oscillation if this is set
in SD43770 $SA_OSCILL_CTRL_MASK.
Note:
MD 10710 $MN_PROG_SD_RESET_SAVE_TAB can be be set so that the value written by the part
program is transferred to the active file system on reset (that is the value is
retained after reset.)
43900 TEMP_COMP_ABS_VALUE - K3
- Position-independent temperature compensation value DOUBLE Immediately
-
808d-me42 - 0.0 - - ReadOnly M
808d-me62 - 0.0 - - ReadOnly M
808d-te42 - 0.0 - - ReadOnly M
808d-te62 - 0.0 - - ReadOnly M
808d-mte40 - 0.0 - - 7/7 U
808d-mte60 - 0.0 - - 7/7 U
Description: The position-independent temperature compensation value is defined by SD43900
$SA_TEMP_COMP_ABS_VALUE.
-
The machine axis traverses this additional compensation value as soon as the position-
independent
temperature compensation
has been activated (MD32750 $MA_TEMP_COMP_TYPE =
1 oder 3).
SD irrelevant for ......
MD32750 $MA_TEMP_COMP_TYPE = 0 or 2
Related to ....
MD32750 $MA_TEMP_COMP_TYPE Temperature compensation type
MD32760 $MA_COMP_ADD_VELO_FACTOR Velocity overshoot caused by compensation
43910 TEMP_COMP_SLOPE - K3
- Lead angle for position-dependent temperature compensation DOUBLE Immediately
-
808d-me42 - 0.0 - - ReadOnly M
808d-me62 - 0.0 - - ReadOnly M
808d-te42 - 0.0 - - ReadOnly M
808d-te62 - 0.0 - - ReadOnly M
808d-mte40 - 0.0 - - 7/7 U
808d-mte60 - 0.0 - - 7/7 U
NC setting data
Parameter Manual
372 List Manual, 01/2017
