Siemens SINUMERIK 808D Parameter Manual

Par. No. Name Min Max Factory
setting
Unit Data type Effective Can be
changed
p1415 Speed setpoint filter 1 type 0 2 0 - I16 IM T, U
Description: Sets the type for speed setpoint filter 1.
●
0: Low pass: PT1
● 1: Low pass: PT2
●
2: General 2nd-order filter
Dependency:
● PT1 low pass: p1416
● PT2 low pass: p1417, p1418
●
General filter: p1417 ... p1420
p1416 Speed setpoint filter 1 time
constant
0.00 5000.00 0.00 ms Float IM T, U
Description: Sets the time constant for the speed setpoint filter 1 (PT1).
This parameter is only effective if the filter is set as a PT1 low pass.
Dependency: p1414, p1415
p1417 Speed setpoint filter 1 de‐
nominator natural frequency
0.5 16000.0 1999.0 Hz Float IM T, U
Description: Sets the denominator natural frequency for speed setpoint filter 1 (PT2, general filter).
This parameter is only effective if the speed filter is parameterized as a PT2 low pass or as general filter.
The filter is only effective if the natural frequency is less than half of the sampling frequency.
Dependency: p1414, p1415
p1418 Speed setpoint filter 1 de‐
nominator damping
0.001 10.000 0.700 - Float IM T, U
Description: Sets the denominator damping for velocity setpoint filter 1 (PT2, general filter).
This parameter is only effective if the speed filter is parameterized as a PT2 low pass or as general filter.
Dependency: p1414, p1415
p1419 Speed setpoint filter 1 nu‐
merator natural frequency
0.5 16000.0 1999.0 Hz Float IM T, U
Description: Sets the numerator natural frequency for speed setpoint filter 1 (general filter).
This parameter is only effective if the speed filter is set as a general filter.
The filter is only effective if the natural frequency is less than half of the sampling frequency.
Dependency: p1414, p1415
p1420 Speed setpoint filter 1 nu‐
merator damping
0.000 10.000 0.700 - Float IM T, U
Description: Sets the numerator damping for speed setpoint filter 1 (general filter).
This parameter is only effective if the speed filter is set as a general filter.
Dependency: p1414, p1415
p1460 Speed controller P gain
adaptation speed, lower
0.000 999999.0
00
0.300 Nms/
rad
Float IM T, U
Description: Sets the P gain of the speed controller before the adaptation speed range.
This value corresponds to the basic setting of the P gain of the speed controller without adaptation.
SINAMICS parameters
7.1 SINAMICS V70 parameters
Parameter Manual
516 List Manual, 01/2017
