Siemens SINUMERIK 808D Parameter Manual

Par. No. Name Min Max Factory
setting
Unit Data type Effective Can be
changed
p1462 Speed controller integral
time adaptation speed lower
0.00 100000.0
0
20.00 ms Float IM T, U
Description: Sets the integration time of the speed controller before the adaptation speed range.
This value corresponds to the basic setting of the integral time of the speed controller without adaptation.
p1520 Torque limit upper/motoring -1000000
.00
2000000
0.00
0.00 Nm Float IM T, U
Description: Sets the fixed upper torque limit or the torque limit when motoring.
Note:
Negative values when setting the upper torque limit (p1520 < 0) can result in the motor accelerating in an
uncontrollable fashion.
The maximum value depends on the maximum torque of the connected motor.
Dependency: p1521
p1521 Torque limit lower/regenera‐
tive
-2000000
0.00
1000000.
00
0.00 Nm Float IM T, U
Description: Sets the fixed lower torque limit or the torque limit when regenerating.
Note:
Positive values when setting the lower torque limit (p1521 > 0) can result in the motor accelerating in an
uncontrollable fashion.
The maximum value depends on the maximum torque of the connected motor.
Dependency: p1520
p1656 Activates current setpoint fil‐
ter
- - 0001 bin - U16 IM T, U
Description: Setting for activating/de-activating the current setpoint filter.
If not all of the filters are required, then the filters should be used consecutively starting from filter 1.
Dependency: The individual current setpoint filters are parameterized as of p1657.
p1657 Current setpoint filter 1 type 1 2 1 - I16 IM T, U
Description: Sets the current setpoint filter 1 as low pass (PT2) or as extended general 2nd-order filter.
●
1: Low pass: PT2
● 2: General 2nd-order filter
Dependency: Current setpoint filter 1 is activated via p1656.0 and parameterized via p1657 ... p1661.
p1658
Current setpoint filter 1 de‐
nominator natural frequency
0.5 16000.0 1999.0 Hz Float IM T, U
Description: Sets the denominator natural frequency for current setpoint filter 1 (PT2, general filter).
Dependency: Current setpoint filter 1 is activated via p1656.0 and parameterized via p1657 ... p1661.
p1659 Current setpoint filter 1 de‐
nominator damping
0.001 10.000 0.700 - Float IM T, U
Description: Sets the denominator damping for current setpoint filter 1.
Dependency: Current setpoint filter 1 is activated via p1656.0 and parameterized via p1657 ... p1661.
p1660 Current setpoint filter 1 nu‐
merator natural frequency
0.5 16000.0 1999.0 Hz Float IM T, U
Description: Sets the numerator natural frequency for current setpoint filter 1 (general filter)
Dependency: Current setpoint filter 1 is activated via p1656.0 and parameterized via p1657 ... p1661.
SINAMICS parameters
7.1 SINAMICS V70 parameters
Parameter Manual
List Manual, 01/2017 517
