10820 EXTERN_INTERRUPT_NUM_RETRAC EXP, N12 FBFA
- Interrupt number for rapid retraction (G10.6) BYTE PowerOn
-
- - 2 1 8 2/2 M
Description: Number of the interrupt input triggering rapid retraction to the position programmed
with G10.6 in ISO mode.
10880 MM_EXTERN_CNC_SYSTEM N01, N12 FBFA
- Definition of the control system to be adapted DWORD PowerOn
-
808d-me42 - 1 1 1 0/0 S
808d-me62 - 1 1 1 0/0 S
808d-te42 - 2 2 2 0/0 S
808d-te62 - 2 2 2 0/0 S
808d-mte40 - 1 1 5 7/2 M
808d-mte60 - 1 1 5 7/2 M
Description: Definition of the external CNC system whose part programs are to be executed on the
SINUMERIK control in addition to SINUMERIK code (ISO_1):
1: ISO_21: System Fanuc0 milling (5.1 and higher)
2: ISO_31: System Fanuc0 turning (P5.2 and higher)
3: External language via OEM application (P6.2 and higher)
4: ISO_22: System Fanuc0 Milling (P7 and higher)
5: ISO_32: System Fanuc0 Turning (P7 and higher)
10881 MM_EXTERN_GCODE_SYSTEM N01, N12 FBFA
- ISO_3 Mode: GCodeSystem DWORD PowerOn
-
808d-me42 - 0 0 2 0/0 S
808d-me62 - 0 0 2 0/0 S
808d-te42 - 1 0 2 1/1 M
808d-te62 - 1 0 2 1/1 M
808d-mte40 - 0 0 2 7/2 M
808d-mte60 - 0 0 2 7/2 M
Description: Definition of the GCodeSystem to be actively executed in ISO_3 Mod (turning):
Value = 0 : ISO_3: Code system B
Value = 1 : ISO_3: Code system A
Value = 2 : ISO_3: Code system C
10882 NC_USER_EXTERN_GCODES_TAB N12 FBFA
- List of user-specific G commands of an external NC language STRING PowerOn
-
- 60 - - - 1/1 M
Description: List of G commands of external NC languages which have been reconfigured by the user.
The implemented G commands are to be taken from the current Siemens documentation for
this programming language.
The list is structured as follows:
Even address: G command to be changed
Subsequent odd address: New G command
Machine data
3.2 General machine data
Parameter Manual
54 List Manual, 01/2017
