7: Reserved for system functions: trace
8: Reserved for system functions: trace
9: Reserved for system functions: action log
11298 PROTOC_PREPTIME_CONTROL N01 -
- Interruption time prep time level in seconds. DOUBLE PowerOn
-
808d-me42 10 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
- - 0/0 S
808d-me62 10 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
- - 0/0 S
808d-te42 10 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
- - 0/0 S
808d-te62 10 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
- - 0/0 S
808d-mte40 10 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
- - 1/1 M
808d-mte60 10 1.0, 1.0, 1.0, 1.0, 1.0,
1.0, 1.0, 1.0...
- - 1/1 M
Description: Time in seconds, for which the prep time level may be blocked. If the PREP does not
manage to pass through within the set time, the cyclic events are not logged. It is
thus ensured that operation cannot be completely blocked by data recording.
The individual values apply to the users of the logging function, which are assigned
the following functions:
0: Reserved for system functions: simultaneous recording, simulation, synchronized
action analysis
1: Reserved for system functions: determining program runtimes, multi-step editor
2: Reserved for OEM applications
3: Reserved for OEM applications
4: Reserved for OEM applications
5: Reserved for system functions: trace
6: Reserved for system functions: trace
7: Reserved for system functions: trace
8: Reserved for system functions: trace
9: Reserved for system functions: action log
11300 JOG_INC_MODE_LEVELTRIGGRD N01 H1, R1
- INC and REF in jog mode BOOLEAN PowerOn
-
- - TRUE 0 - 1/1 M
Description: 1: Jog mode for JOG-INC and reference point approach
JOG-INC:
When the traversing key is pressed in the required direction (e.g. +), the axis begins
to traverse the set increment. If the key is released before the increment has been
completely the traversed,
the movement is interrupted and the axis stops. If the same
key is pressed again, the axis completes the remaining distance-to-go until this is 0.
0: Continuous operation for JOG-INC and reference point approach
JOG-INC:
When the traversing key is pressed (first rising edge) the axis travels the whole set
increment. If the same key is pressed again (second rising edge) before the axis has
completed traversing the increment, the movement is canceled, i.e. not completed.
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 67
