The differences in axis travel behavior between the jog mode and continuous operation
in incremental traversing are described in detail in the relevant chapters.
For travel behavior in reference point approach see
References: /FB/, R1, "Reference Point Approach"
MD irrelevant for:
Continuous traversing (JOG continuous)
11310 HANDWH_REVERSE N09 H1
- Threshold for direction change handwheel BYTE PowerOn
-
- - 2 0 - 2/2 M
Description: Handwheel travel:
Value = 0:
No immediate travel in the opposite direction
Value > 0:
Immediate travel in the opposite direction if the handwheel is turned at least the
stated number of pulses in the opposite direction.
Whether this machine data is also active for handwheel travel with DRF depends on bit10
of MD20624 $MC_HANDWH_CHAN_STOP_COND.
11320 HANDWH_IMP_PER_LATCH N09 H1
- Handwheel pulses per detent position DOUBLE PowerOn
-
- 6 1., 1., 1., 1., 1., 1. - - 2/2 M
Description: The connected handwheels are adapted to the control in MD11320
$MN_HANDWH_IMP_PER_LATCH.
The number of pulses generated by the handwheel for each handwheel detent position has
to be entered. The handwheel pulse weighting must be defined separately for each
connected handwheel (1
to 3). With this adaptation, each handwheel detent position has
the same effect as one press of the traversing key in incremental traversal.
Entering a negative value reverses the direction of rotation of the handwheel.
Related to:
MD31090 $MA_JOG_INCR_WEIGHT
(weighting of an increment of a machine axis for
INC/manual).
11322 CONTOURHANDWH_IMP_PER_LATCH N09 H1
- Contour handwheel pulses per detent position DOUBLE PowerOn
-
- 6 1., 1., 1., 1., 1., 1. - - 2/2 M
Description: Adaptation factor to the hardware of the contour handwheel:
Enter the number of pulses issued per detent position by the contour
handwheel.
Because of this normalization, a detent position of the contour handwheel
corresponds to one press of a key with incremental jog processes.
Sign reversal reverses the direction of evaluation.
Machine data
3.2 General machine data
Parameter Manual
68 List Manual, 01/2017
