11330 JOG_INCR_SIZE_TAB EXP, N09 H1
- Increment size for INC/handwheel DOUBLE PowerOn
-
- 5 1., 10., 100., 1000.,
10000.
0.0 - 1/1 M
Description: In incremental traversal or handwheel travel, the number of increments to be traversed
by the axis can be defined by the user, e.g. via the machine control panel.
In addition to the variable increment size (INCvar), 5 fixed increment sizes (INC...)
can also be set.
The increment size for each of these 5 fixed increments is defined collectively for
all axes by entering values in JOG_INCR_SIZE_TAB [n]. The default setting is INC1,
INC10, INC100, INC1000 and INC10000.
The entered increment sizes are also active for DRF.
The size of the variable increment is defined in SD41010 $SN_JOG_VAR_INCR_SIZE.
Related to:
MD31090 $MA_JOG_INCR_WEIGHT (weighting of an increment for INC/manual)
NC/PLC interface signal DB3300 DBX1001.0-4,1005.0-4,1009.0-4
(Geometry axis 1-3 active machine function: INC1; ...; INC10000)
NC/PLC interface signal DB390x DBX5.0 - .5
(active machine function: INC1; ...; INC10000).
11346 HANDWH_TRUE_DISTANCE N01 H1, P1, W1
- Handwheel default path or velocity BYTE PowerOn
-
808d-me42 - 6 0 7 1/1 M
808d-me62 - 6 0 7 1/1 M
808d-te42 - 6 0 7 1/1 M
808d-te62 - 6 0 7 1/1 M
808d-mte40 - 1 0 7 1/1 M
808d-mte60 - 1 0 7 1/1 M
Description: Setting the behavior for traversing with the handwheel, contour handwheel and with
FDA=0:
Value = 1: (default value)
The default settings of the handwheel are path inputs. No pulses are lost. Residual
axis motions occur as a result of the limitation to a maximal permissible velocity.
Value = 0:
The default settings of the handwheel are velocity inputs. The axes stop as soon as
the handwheel stops. The motion is immediately braked if no pulses come from the
handwheel in an interpolation cycle. Therefore, only a short residual motion of the
axes can occur as a result of the braking ramp. The handwheel pulses do not supply a
path default.
Value = 2:
The default settings of the handwheel are velocity inputs. The axes are intended to
stop
as soon
as the handwheel stops. The motion is immediately braked if no pulses come
from the handwheel in an interpolation cycle. However, in contrast to value = 0 braking
is not along the shortest possible path but to the next possible point in an intended
grid.
Each increment in the grid corresponds to a displacement which the selected axis
travels per handwheel grid position (see MD31090 $MA_JOG_INCR_WEIGHT and
see MD31090 $MA_JOG_INCR_WEIGHT and,
MD11330 $MN_JOG_INCR_SIZE_TAB,
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 69
