MD11717 $MN_D_NO_FCT_CYCLE_NAME is only active in Siemens mode (G290).
No more than one M/T/D function replacement can be active per part program line.
A modal subprogram call must not be programmed in the block with the D function
replacement. Furthermore, neither subprogram return nor part program end are allowed.
In the event of a conflict alarm 14016 is output.
12000 OVR_AX_IS_GRAY_CODE EXP, N10 V1, Z1
- Axis feedrate override switch Gray-coded BOOLEAN PowerOn
-
- - TRUE 0 - 1/1 M
Description: This machine data is used to adapt the axis feed override switch to the interface
coding of the PLC interface.
1: The 5 low-order bits of the PLC interface signal DB380x DBX0 (Feed override A-H)
are interpreted as a Gray code. The value which is read corresponds to a switch
setting. It is used as an index for selecting the correct override factor from the
table of MD12010 $MN_OVR_FACTOR_AX_SPEED [n].
0: The feed override byte of the PLC interface is interpreted as a binary
representation of the override value in percent (limit 200 percent).
Related to:
NC/PLC interface signal DB380x DBX0 (Feed override A-H), (axis-specific)
MD12010 $MN_OVR_FACTOR_AX_SPEED [n]
(Evaluation of the axis feed override switch)
12010 OVR_FACTOR_AX_SPEED EXP, N10 V1, Z1
- Evaluation of axis feedrate override switch DOUBLE PowerOn
-
- 31 0.00, 0.01, 0.02, 0.04,
0.06, 0.08, 0.10, 0.20...
0.00 2.00 1/1 M
Description: Evaluation of the axis velocity override switch with gray-coded interface.
Not relevant with:
MD12000 $MN_OVR_AX_IS_GRAY_CODE = 0
Related to:
NC/PLC interface signal DB380x DBX0 (Feed override A-H), (axis-specific)
12020 OVR_FEED_IS_GRAY_CODE EXP, N10 V1, Z1
- Path feedrate override switch Gray-coded BOOLEAN PowerOn
-
- - TRUE 0 - 1/1 M
Description: This machine data is used to adapt the path feed override switch to the interface
coding of the PLC interface.
1: The 5 low-order bits of the NC/PLC interface signal DB380x DBX0 (Feed override
A-H) are interpreted as a Gray code. The value which is read corresponds to a switch
setting. It is used as an index for selecting the correct override factor from the
table of MD12030 $MN_OVR_FACTOR_FEEDRATE [n].
0: The feed override byte of the PLC interface is interpreted as a binary
representation of the override value in percent (limit 200 percent).
Related to:
NC/PLC interface signal DB380x DBX0 (Feed override A-H)
MD12030 $MN_OVR_FACTOR_FEEDRATE [n]
(Evaluation of the path feed override switch)
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 77
