12030 OVR_FACTOR_FEEDRATE EXP, N10 V1, B1, Z1
- Evaluation of path feedrate override switch DOUBLE PowerOn
-
- 31 0.00, 0.01, 0.02, 0.04,
0.06, 0.08, 0.10, 0.20...
0.00 2.00 1/1 M
Description: Evaluation of the feedrate override switch with gray-coded interface.
Special function of the 31st value for the velocity control:
The setting of the 31st override value defines the dynamic reserves which take the
velocity control to be an excessive increase in the path feed. The setting should
correspond to the highest override factor actually used.
Not relevant with:
MD12020 $MN_OVR_FEED_IS_GRAY_CODE = 0
Related to:
NC/PLC interface signal DB380x DBX0 (Feed override A-H)
12040 OVR_RAPID_IS_GRAY_CODE EXP, N10 V1, Z1
- Rapid traverse override switch Gray-coded BOOLEAN PowerOn
-
- - TRUE 0 - 1/1 M
Description: This machine data is used to adapt the rapid traverse override switch to the interface
coding of the PLC interface.
1: The 5 low-order bits of the PLC interface signal DB3200 DBX5 (Rapid traverse
override A-H) are interpreted as a Gray code. The value which is read corresponds to
a switch setting.
It is used as an index for selecting the correct override factor from the table of
MD12050 $MN_OVR_FACTOR_RAPID_TRA[n].
0: The rapid traverse override byte of the PLC interface is interpreted as a binary
representation of the override value in percent (limit 200 percent).
Related to:
NC/PLC interface signal DB3200 DBX5 (Rapid traverse override A-H)
MD12050 $MN_OVR_FACTOR_RAPID_TRA[n]
(Evaluation of the rapid traverse override switch)
12050 OVR_FACTOR_RAPID_TRA EXP, N10 V1, Z1
- Evaluation of rapid traverse override switch DOUBLE PowerOn
-
- 31 0.00, 0.01, 0.02, 0.04,
0.06, 0.08, 0.10, 0.20...
0.00 1.00 1/1 M
Description: Evaluation of the rapid traverse override switch with gray-coded interface.
Not relevant with:
MD12040 $MN_OVR_RAPID_IS_GRAY_CODE = 0
Related to:
NC/PLC interface signal DB3200 DBX5 (Rapid traverse override A-H)
12060 OVR_SPIND_IS_GRAY_CODE EXP, N10 V1, Z1
- Spindle override switch Gray-coded BOOLEAN PowerOn
-
- - TRUE 0 - 1/1 M
Description: This machine data is used to adapt the spindle speed override switch to the interface
coding of the PLC interface.
Machine data
3.2 General machine data
Parameter Manual
78 List Manual, 01/2017
