Bit 2 Feed disable for all axes
Bit 3 EMERGENCY STOP
Bit 4 PLC in stop
Bit 5 Alarm log
Bit 6 Definition for alarm or message (1: Alarm, 0: Message
Bit 7 Delete at POWER ON
15700 LANG_SUB_NAME N01 K1
- Name for substitution subroutine STRING PowerOn
-
- - - - - 2/2 M
Description: Name of the user program called on the basis of a substitution configured by MD30465
$MA_AXIS_LANG_SUB_MASK.
The user program is called with the path configured by MD15702 $MN_LANG_SUB_PATH.
15702 LANG_SUB_PATH N01 K1
- Call path for substitution subroutine BYTE PowerOn
-
- - 0 0 2 2/2 M
Description: Path with which the user program set by MD15700 $MN_LANG_SUB_NAME is called on the
basis of a substitution configured by MD30465 $MA_AXIS_LANG_SUB_MASK:
0: /_N_CMA_DIR (default)
1: /_N_CUS_DIR
2: /_N_CST_DIR
17000 EXTENSIONS_OF_BIN_FILES EXP -
- Extensions of binary files STRING PowerOn
-
- 20 JPG, GIF, PNG, BMP,
PDF, ICO, HTM, CLC
- - 2/2 M
Description: Extensions of files which are saved in the binary format in the passive NCKs file
system.
For these files, there are no restrictions regarding the content.
For ASCII content (e.g. HTM) any line length is possible; this is not permissible for
NC programs (e.g. MPF, SPF and DEF).
Each extension must comprise precisely three uppercase letters.
17300 CNC_LOCK_WARNING_TIME EXP, N01 -
- Prewarning time for triggering the CNC lock function DWORD PowerOn
-
- - 30 1 90 1/1 I
Description: Definition of the time period for triggering the CNC lock function from which the
clearable information alarms of this function will be output (in days).
17400 OEM_GLOBAL_INFO A01, A11 -
- OEM version information STRING PowerOn
-
- 5 - - - 2/2 I
Description: A version information freely available to the user
(is indicated in the version screen)
Machine data
3.2 General machine data
Parameter Manual
86 List Manual, 01/2017
