Siemens SINUMERIK 808D Parameter Manual

13230 MEAS_PROBE_SOURCE N10, N09 -
- Probe simulation BYTE PowerOn
-
- - 0 0 9 3/2 M
Description: Simulation of the probe only works when all axes are simulated.
Value = 0: the probe is triggered on the programmed end position.
Value = 1-8: the probe is triggered via digital output with the number=value.
Value = 9: reserved
13231 MEAS_PROBE_OFFSET N10, N09 -
mm/inch,
degrees
Probe offset DOUBLE Immediately
-
- - 0.1 - - 7/7 U
Description: The switching position of the probe is offset by the value.
The offset is only active with the simulated probes and MD 13230
$MN_MEAS_PROBE_SOURCE=0.
14510 USER_DATA_INT N03 P3, "PLC-Maschinendaten", P4,
"PLC-Maschinendaten"
- User data (INT) DWORD PowerOn
-
- 32 0, 0, 0, 0, 0, 0, 0, 0... -32768 32767 7/3 I
Description: User data is stored in the NCK-PLC interface, and can already be read from the machine
data block by the PLC user during the runup of the PLC.
14512 USER_DATA_HEX N03 P3, "PLC-Maschinendaten", P4,
"PLC-Maschinendaten"
- User data (HEX) DWORD PowerOn
-
- 32 0, 0, 0, 0, 0, 0, 0, 0... 0 0x0FF 7/3 I
Description: User data is stored in the NCK-PLC interface, and can already be read from the machine
data block by the PLC user during the runup of the PLC.
14514 USER_DATA_FLOAT N03 P3, "PLC-Maschinendaten", P4,
"PLC-Maschinendaten"
- User data (FLOAT) DOUBLE PowerOn
-
- 8 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
-3.40e38 3.40e38 7/3 I
Description: User data is stored in the NCK-PLC interface, and can already be read from the machine
data block by the PLC user during the runup of the PLC.
14516 USER_DATA_PLC_ALARM N03 A2, P3
- User data (HEX) BYTE PowerOn
-
- 128 0, 0, 0, 0, 0, 0, 0, 0... 0 - 7/3 U
Description: Configuration of alarm responses to user PLC alarms
Bit 0 NC start disabled
Bit 1 Read-in disable
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 85
