13: 0x2000 Output warnings of the Terminal Modules
13160 SINAMICS_MAX_SLAVE_ADDRESS N04, N10 -
- Highest SINAMICS slave address DWORD PowerOn
-
808d-me42 4 0, 0, 0, 0 0 - ReadOnly M
808d-me62 4 0, 0, 0, 0 0 - ReadOnly M
808d-te42 4 0, 0, 0, 0 0 - ReadOnly M
808d-te62 4 0, 0, 0, 0 0 - ReadOnly M
808d-mte40 4 0, 0, 0, 0 0 - 7/2 M
808d-mte60 4 0, 0, 0, 0 0 - 7/2 M
Description: Highest slave/device address supported per bus
All slaves/devices with an address higher than the address set here are ignored by the
NCK
Value 0: No limitation
13200 MEAS_PROBE_LOW_ACTIVE N10, N09 M5
- Polarity reversal of sensor BOOLEAN PowerOn
-
- 2 FALSE, FALSE 0 - 3/3 U
Description: This MD defines the electrical polarity of each connected sensor.
Value 0:
(Default setting)
Non-deflected state 0 V
Deflected state 24 V
Value 1:
Non-deflected state 24 V
Deflected state 0 V
The programmed edges of the sensor are independent of the electrical polarity, and are
to be regarded as purely mechanical. The programming of a positive edge always means
the transition from the non-deflected into the deflected state. The programming of a
negative edge always means the transition from the deflected into the non-deflected
state.
13220 MEAS_PROBE_DELAY_TIME N10, N09 FBA
s Delay time between probe deflection and recognition DOUBLE NEW CONF
-
- 2 0.0, 0.0 0 0.1 3/3 U
Description: For probes with, for example, radio transmission, the probe deflection can be detected
in the NC only with delay.
With this MD, the transmission link delay between the probe deflection and its
detection is set in the control.
The measured value is corrected internally by the control by the distance that
corresponds to the traversing motion during this time before measuring (modeling).
As the modeling does not work with the expected accuracy at higher position control
cycles, the delay time is limited independently of the input value to 31 position
control cycles).
Machine data
3.2 General machine data
Parameter Manual
84 List Manual, 01/2017
