Meaning: Tool status "to unload" remains unchanged
Bit no.: 10 Bit value: 1 hex value: 'H400'
Meaning: Tool status "to unload" is deleted
Bit no.: 11 Not permitted (tool status "to load")
Bit no.: 12 Bit value: 0 Not permitted (tool status "master tool")
Bit no.: 13 Not permitted (reserved)
The default setting corresponds to the previous behavior.
Impermissible bits are filtered and not displayed in the limit mask.
Bits not defined here are ignored when writing the machine data.
17520 TOOL_DEFAULT_DATA_MASK N09 FBWsl
- Create new tool: default settings DWORD PowerOn
-
808d-me42 - 0 0 0x1F 0/0 S
808d-me62 - 0 0 0x1F 0/0 S
808d-te42 - 0 0 0x1F 0/0 S
808d-te62 - 0 0 0x1F 0/0 S
808d-mte40 - 0 0 0x1F 7/2 M
808d-mte60 - 0 0 0x1F 7/2 M
Description: When defining a tool for the first time (bits 0, 1, 2) or the magazine locations (bit
3) for the first time, certain data of the tool can be set to fixed default values.
Bit 4 can couple the magazine location status 'Overlapping allowed' ('H2000') to the
value of the magazine location status 'disabled' ('H1'). This can prevent simple
applications from dealing with data which do not necessarily have to be assigned
individual values.
Bit no.: 0 Bit value: 0 Hex value: -
Meaning: Default value of tool status ($TC_TP8), bit1=0 ='not released'
Bit no.: 0 Bit value: 1 Hex value: 'H1'
Meaning: Default value of tool status ($TC_TP8), bit1=1 ='released'
Bit no.: 1 Bit value: 0 Hex value: -
Meaning: Default value of tool status ($TC_TP8), bit6=0 ='not fixed-location-coded'
Bit no.: 1 Bit value: 1 Hex value: 'H2'
Meaning: Default value of tool status ($TC_TP8), bit6=1 ='fixed-location-coded'
Bit no.: 2 Bit value: 0 Hex value: -
Meaning: The tool is only accepted in the tool group when the explicit write command
is used for the tool name. Only then can it be loaded via programming.
Bit no.: 2 Bit value: 1 Hex value: 'H4'
Meaning: The tool is automatically accepted in the tool group corresponding to the
tool name when it is defined for the first time. The tool can then be changed using
the default name ("t" = t-No.).
The term 'tool name' ($TC_TP2) can be hidden from the user. (This only makes sense if
you
do not
use replacement tools or if the tool name is not written explicitly, as this
may give rise to data consistency problems.)
Bit no.: 3 Bit value: 0 Only with TMMG: Default value of location type
($TC_TP7)=9999=not defined
Bit no.: 3 Bit value: 1 Hex value: 'H8'
Meaning: Only with TMMG: Default value of location type ($TC_TP7) = 1 and consequently
the
default value
of magazine location type ($TC_MPP2)=1. This means that all magazine
locations can accept all tools.
Bit no.: 4 Bit value: 0 Hex value: -
Machine data
3.2 General machine data
Parameter Manual
88 List Manual, 01/2017
