Meaning: Only with TMMG + active consider adjacent location: With SET/RESET of the
magazine location status 'disabled', the magazine location status 'Overlapping
allowed' remains unchanged.
Bit no.: 4 Bit value: 1 Hex value: 'H10'
Meaning: Only with TMMG + active consider adjacent location: With SET/RESET of the
magazine location status 'disabled', the magazine location status 'Overlapping
allowed' is automatically SET/RESET.
17530 TOOL_DATA_CHANGE_COUNTER EXP, N01 -
- Mark tool data change for HMI DWORD PowerOn
-
808d-me42 - 0 0 0x1F 0/0 S
808d-me62 - 0 0 0x1F 0/0 S
808d-te42 - 0 0 0x1F 0/0 S
808d-te62 - 0 0 0x1F 0/0 S
808d-mte40 - 0 0 0x1F 7/2 M
808d-mte60 - 0 0 0x1F 7/2 M
Description: HMI display support. This data enables individual data to be explicitly taken into
account or not taken into account in the OPI variables (block C/S) toolCounter,
toolCounterC, toolCounterM.
Bit no. : 0 Bit value: 0 Hex value: -
Meaning: Changes to the values of the tool status ($TC_TP8) are not taken into account
in toolCounterC
Bit no. : 0 Bit value: 1 Hex value: 'H1'
Meaning: Changes to the values of the tool status ($TC_TP8) are taken into account in
toolCounterC
Bit no. : 1 Bit value: 0 Hex value: -
Meaning: Changes to the values of the remaining number of tools ($TC_MOP4) are not
taken into account in toolCounterC
Bit no. : 1 Bit value: 1 Hex value: 'H2'
Meaning: Changes to the values of the remaining number of tools ($TC_MOP4) are taken
into account in toolCounterC
Bit no. : 2 Bit value: 0 Hex value: -
Meaning: Changes to the values of the tool data are not taken into account in the tool
data update service
Bit no. : 2 Bit value: 1 Hex value: 'H4'
Meaning: Changes to the values of the tool data are taken into account in the tool data
update service
Bit no. : 3 Bit value: 0 Hex value: -
Meaning: Changes to the values of the magazine data are not taken into account in the
tool data update service
Bit no. : 3 Bit value: 1 Hex value: 'H8'
Meaning: Changes to the values of the magazine data are taken into account in the tool
data update service.
Bit no. : 4 Bit value: 0 Hex value: -
Meaning: Changes to the values of the ISO tool offset data are not taken into account
in the tool data update service
Bit no. : 4 Bit value: 1 Hex value: 'H10' Meaning: Changes to the values of the
ISO tool offset data are taken into account in the tool data update service
The statements "Changes to the values of the tool status" and "Changes to the values
of
the remaining number of tools" refer not only to value changes effected by internal
processes in the NC but also to value changes produced by writing the corresponding
system variables.
