MD18097 $MN_MM_TYPE_CC_TOA_PARAM=2
"A" can then be programmed for parameter $TC_DPC1.
Buffered user memory is used. A value change leads to reconfiguration of the buffered
memory.
Related to:
MD18096 $MN_MM_NUM_CC_TOA_PARAM
18098 MM_NUM_CC_MON_PARAM N02, N09 FBWsl
- Number of monitoring data per tool for compile cycles DWORD PowerOn
-
- - 0 0 64 2/2 M
Description: Number of monitoring data (of type Integer) which can be created per tool, and which
are available to the user or the compile cycle.
This MD increases the buffered memory requirement by sizeof(int)*max. number of
cutting edges.
Related to:
MD18080 $MN_MM_TOOL_MANAGEMENT_MASK
MD18100 $MN_MM_NUM_CUTTING_EDGES_IN_TOA
18099 MM_TYPE_CC_MON_PARAM N02, N09 FBWsl
- Type of OEM monitor data (SRAM) DWORD PowerOn
-
808d-me42 64 1, 1, 1, 1, 1, 1, 1, 1... 1 1 2/2 M
808d-me62 64 1, 1, 1, 1, 1, 1, 1, 1... 1 1 2/2 M
808d-te42 64 1, 1, 1, 1, 1, 1, 1, 1... 1 1 2/2 M
808d-te62 64 1, 1, 1, 1, 1, 1, 1, 1... 1 1 2/2 M
808d-mte40 64 3, 3, 3, 3, 3, 3, 3, 3... 1 6 2/2 M
808d-mte60 64 3, 3, 3, 3, 3, 3, 3, 3... 1 6 2/2 M
Description: Individual types can be assigned to the parameters in this way. The array index n can
accept values from 0 to the value of MD18098 $MN_MM_NUM_CC_MON_PARAM.
Possible values of the MD = 1, 2, 3, 4 and 6 represent the NC language types
1 BOOL,
2 CHAR,
3 INT,
4 REAL and
6 AXIS.
The FRAME type cannot be defined here.
(The type STRING is explicitly not possible here. The value 5 is treated like value 2.)
Example:
MD18098 $MN_MM_NUM_CC_MON_PARAM=1
MD18099 $MN_MM_TYPE_CC_MON_PARAM=2
"A" can then be programmed for the parameter $TC_MOPC1.
Buffered user memory is used. A value change leads to reconfiguration of the buffered
memory.
Related to:
MD18100 $MN_MM_NUM_CUTTING_EDGES_IN_TOA
MD18098 $MN_MM_NUM_CC_MON_PARAM
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 95
