18102 MM_TYPE_OF_CUTTING_EDGE N02, N09 W1
- Type of D No. programming (SRAM) DWORD PowerOn
-
808d-me42 - 0 0 1 0/0 S
808d-me62 - 0 0 1 0/0 S
808d-te42 - 0 0 1 0/0 S
808d-te62 - 0 0 1 0/0 S
808d-mte40 - 0 0 1 2/2 M
808d-mte60 - 0 0 1 2/2 M
Description: This MD activates the 'flat D number management'.
The default value is zero. This means that the NCK manages the T and D numbers.
Value: Meaning
-----------------------------------------------------------------------------------
0: No 'flat D number management' active
1: 'Flat D number' function is active
18108 MM_NUM_SUMCORR N02, N09 W1
- Resulting offsets in TO area (SRAM) DWORD PowerOn
-
808d-me42 - -1 -1 9000 ReadOnly M
808d-me62 - -1 -1 9000 ReadOnly M
808d-te42 - -1 -1 9000 ReadOnly M
808d-te62 - -1 -1 9000 ReadOnly M
808d-mte40 - -1 -1 9000 7/2 M
808d-mte60 - -1 -1 9000 7/2 M
Description: Total number of resulting offsets in the NCK.
The value = -1 means that the number of resulting offsets is equal to the number of
cutting edges multiplied by the number of resulting offsets per cutting edge.
A value > 0 and < "number of cutting edges multiplied by the number of resulting
offsets per cutting edge" means that a maximum "number of resulting offsets per
cutting edge" can be defined per cutting edge but do not have to be. This means that
buffered
memory can be used economically. Only those cutting edges for which expliicit
data have been defined have a resulting offset data block.
Buffered memory is reserved. The memory requirement for a resulting offset doubles if
"setup offset active" has also been configured, see MD18112 $MN_MM_KIND_OF_SUMCORR.
See also:
MD18100 $MN_MM_NUM_CUTTING_EDGES_IN_TOA,
MD18110 $MN_MM_MAX_SUMCORR_PER_CUTTEDGE
18110 MM_MAX_SUMCORR_PER_CUTTEDGE N02, N09 S7
- Max. number of additive offsets per edge (SRAM) DWORD PowerOn
-
808d-me42 - 1 1 6 ReadOnly M
808d-me62 - 1 1 6 ReadOnly M
808d-te42 - 1 1 6 ReadOnly M
808d-te62 - 1 1 6 ReadOnly M
808d-mte40 - 1 1 6 7/2 M
808d-mte60 - 1 1 6 7/2 M
Description: Maximum number of resulting offsets per cutting edge.
Machine data
3.2 General machine data
Parameter Manual
96 List Manual, 01/2017
