10.04 Operation
2.8 Manual mode
2
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 2-109
Parameters Description Unit
TC Name of the swivel data block
O: Remove swivel head, deselect swivel data block
No entry: No change to set swivel data block
Move clear No: Do not retract tool before swiveling
Z: Move tool axis to retraction position before swiveling
Z, X, Y: Move machining axes to retraction position before swiveling
Tool max: Retract tool in tool direction to software limit switch
Tool inc: Retract tool incrementally in tool direction by the entered value
Swivel plane Swivel new: Define new swivel plane
Swivel additive: Place swivel plane on last swivel plane
Swivel method
A
xial: Swivel coordinate system axiall
y
Direct: Position rotary axes directly
X
A
xis angle (swivel axially) The sequence of axes Degr.
Y
A
xis angle (swivel axially) can be changed to any order Degr.
Z
A
xis angle (swivel axially) with "Alternat.". Degr.
A
A
xis angle (swivel directly) Degr.
B
A
xis angle (swivel directly) Degr.
Direction Preferred direction of rotation given 2 alternatives
+: Larger angle of axis on scale for swivel head/table
-: Smaller angle of axis on scale for swivel head/table
Fix tool tip Follow-up: The position of the tool tip is maintained during swiveling.
No follow-up: The position of the tool tip changes during swiveling.
