Programming with ShopMill 10.04
3.5 Contour millin
g
3
 Siemens AG, 2004. All rights reserved
3-220 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
3.5.15 Chamfering a contour spigot
If you have planned edge breaking, mill a chamfer after that.
Parameters Description Unit
T, D, F, S, V See Sec. "Creating program blocks".
Machining
type
Chamfer
Z0
FS
ZF
Reference point in Z direction (abs.)
Chamfer width; abs
Insertion depth tool tip; abs or inc
mm
mm
mm
