Siemens SINUMERIK 810D Operation/Programming

2
10.04 Operation
2.10
A
utomatic mode
2
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 2-119
Starting program
execution from an
operating area
The program is loaded in "Machine Auto" mode and "Automatic" mode
is activated on the machine control panel.
Cycle Start
 Press the "Cycle Start" key.
The program is started and executed from the beginning. However,
the interface of the previously selected operating area remains on the
screen.
2.10.4 Interrupting a program
Retracting from a
contour
After you have interrupted a program ("NC Stop") in Automatic mode
(e.g. in order to take a measurement on the workpiece and correct the
tool wear values or after tool breakage), you can retract the tool from
the contour in "Machine Manual" mode. In such cases, ShopMill
stores the coordinates of the interruption point and displays the
differences in distance traveled by the axes in "Machine Manual"
mode as a "Repos" (= Reposition) offset in the actual value window.
For details of how to traverse machine axes, please refer to Sec.
"Traversing machine axes".
Repositioning
The "Repos" function repositions the tool on the workpiece contour
after traversal of the machine axes during a program interruption in
Automatic mode.
Jog
 Select "Machine Manual" mode.
Move the axes away from the point of interruption.
Repos
 Press the "Repos" key.
X
...
 Select the axis to be traversed.
+
 Press the "+" or "-" key.
It is not possible to overtravel the point of interruption.
The feedrate override is active.
Warning
The rapid traverse override switch is active.
Non-adjusted Repos offsets are adjusted with program advance and
linear interpolation on switchover to Automatic mode followed by start
with the "Cycle start" key.
