2
10.04 Operation
2.10
utomatic mode
2
ï›™ Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 2-115
2.10 Automatic mode
Auto
In the "Machine Auto" operating mode, you can execute machining
programs and monitor the progress of the current machining operation
online on the screen.
Requirements for
execution
• You have already synchronized the control measuring system with
the machine (i.e. "approached" reference points).
• You have already written the relevant machining program.
• You have checked or entered the necessary offset values, such as
work offsets or tool offsets.
• The required safety interlocks are already active.
Example of program view in "Machine Auto"
Sequential control programs produced with an earlier version of
ShopMill can also be executed in the current sequential control
version. If an older sequential control program is executed once in the
current sequential control version, it is reclassified as being in the
current sequential control version.
You can also execute a Version-6.3 sequential control program in
ShopMill 6.2, provided that you consider the following points:
• If the machining type "Edge finishing" is programmed for a
longitudinal groove in ShopMill 6.3, the parameter is replaced by
"Roughing" in ShopMill 6.2.
• The functions "Deep drilling" and "Circumferential slot"
programmed under ShopMill 6.3 only run in ShopMill 6.2 if you
check the function parameters again in ShopMill 6.2 and confirm
these.
