Scrolling through the
program
 Place the cursor in the program section.
 Press one of the cursor keys.
You move up, down, left, or right in the part program.
Stopping a search
You can interrupt a search at any time.
Abort
 Press the "Abort" softkey.
5.12.2 Editing a G code program
Changing and saving G
blocks
You can edit the selected block and then save it.
Edit
 Press the "Edit" softkey.
 Edit the selected block in the program section.
You are automatically in overwrite mode.
- OR -
Overwrite
 Press the "Overwrite" softkey.
Insert
The softkey changes to "Insert"
You can now insert blocks.
Save
File
 Press the "Save File" softkey.
The changes are applied in the file.
The workpiece graphics are redrawn.

