10.04 Simulation
5.9 Zoomin
g
and
p
annin
g
the work
p
iece
g
ra
p
hics
5
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 5-341
5.9 Zooming and panning the workpiece graphics
You can adjust the size of the displayed graphics to meet your
requirements.
Zooming the view
Details Enlarge
Reduce
 Press the "Details" and "Enlarge Reduce" softkeys.
Enlarge
-or-
+
 Press the "Enlarge" softkey
or press the "+" key.
The graphics viewport is enlarged.
Reducing the view
Details Enlarge
Reduce
 Press the "Details" and "Enlarge Reduce" softkeys.
New softkeys appear on the vertical softkey bar.
Reduce
-or-
 Press the "Reduce" softkey
or press the "-" key.
The graphics viewport is reduced.
Automatic display size
Details Enlarge
Reduce
 Press the "Details" and "Enlarge Reduce" softkeys.
Autom.
Size
 Press the "Autom. Size" softkey.
The viewport is fitted to the window size.
Automatic resizing takes account of the greatest extent of the
workpiece in each axis.
