2
Operation 10.04
2.10 Automatic mode
2
ï›™ Siemens AG, 2004. All rights reserved
2-118 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
When you select a program for the first time for execution, that
contains the cycles "Stock removal towards contour" or "Contour
pocket", the individual stock removal steps or solid machining steps
for the contour pocket are calculated automatically. This process may
take several seconds depending on the complexity of the contour.
2.10.3 Starting/stopping/aborting a program
Shows how to start/stop programs that are loaded in "Machine Auto"
operating mode and resume program execution after abnormal
program termination.
Once the program is loaded in "Machine Auto" mode, and "Automatic"
mode is also activated on the machine control panel, you can start the
program whatever your current operating area, even if you are not in
"Machine Auto" mode.
This start option must be enabled in a machine data code.
Please refer to the machine manufacturer's instructions.
Precondition
No alarms are pending.
The program is selected.
Feedrate enable is active.
Spindle enable is set.
Starting execution
Cycle Start
îš¾ Press the "Cycle Start" key.
The program is started and executed from the start or from the
selected program block onwards.
Stopping the program
Cycle Stop
îš¾ Press the "Cycle Stop" key.
Machining stops immediately, individual blocks do not finish execu-
tion. At the next start, execution is resumed at the same location
where it stopped.
Aborting execution
Reset
îš¾ Press the "Reset" key.
Execution of the program is interrupted. When it is started again, it will
execute from the beginning.
