10.04 Operation
2.13 Tools and tool offsets
2
ï›™ Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 2-153
Oversize (U) In the case of oversize tools, neighboring magazine locations (left and
right adjacent location) are only reserved alternately, i.e. you can only
insert the next tool in the next magazine location but one. (This can
also contain an oversize tool.)
Coded for fixed location (P) You can assign tools to a fixed location, i.e., the tool can only be used
in its present magazine location. After machining, the tool always
returns to its old magazine location.
Monitoring tool use
îš¾ Select the "Tool wear" softkey in the "Tools WOs" operating area.
îš¾ Position the cursor on the tool that you want to monitor.
îš¾ In the column "T/C" select the parameter that you wish to monitor
(T = Tool life, C = Count, W = Wear).
îš¾ Enter a prewarning limit for the tool life, count, or wear.
îš¾ Enter the scheduled service life for the tool, the scheduled
number of workpieces to be machined or the maximum
permissible wear.
The tool is disabled when the tool life, count, or wear is reached.
Entering tool statuses
îš¾ Select the "Tool wear" softkey in the "Tools WOs" operating area.
îš¾ Place the cursor on a tool.
îš¾ Select the option "G" in the first field of the last column if you want
to disable the tool for machining.
-or-
îš¾ Select the option "U" in the second field of the last column if you
want to mark the tool as oversize.
-or-
îš¾ Select the option "P" in the third field of the last column if you
want assign the tool to a fixed magazine location.
The tool properties you have set become active immediately.
