10.04 Operation
2.14 Work offsets
2
ï›™ Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 2-165
Coordinate
transformations
Program The active coordinates of the "Offset" transformation are displayed as
well as the angle set in the "Rotation" transformation by which the
coordinate system rotates.
You cannot edit these values here.
Scale The active scaling factor for the "Scaling" transformation is displayed
for the respective axis.
You cannot edit these values here.
Mirror The mirror axis that was defined by means of the "Mirroring"
transformation is displayed.
You cannot edit these values here.
Total offset
Total The total offset resulting from the base offset and all active work
offsets and coordinate transformations appears.
Additional
axes
With the "Additional axes" softkey, you can display two additional
rotary axes and determine their offset. These additional axes must be
activated via machine data.
Please refer to the machine manufacturer's instructions.
îš¾ Press the "Work offset" softkey in the "Tools WOs" operating
area.
The work offset list appears.
