10.04 Programming with ShopMill
3.5 Contour millin
g
3
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 3-205
UXY Finishing allowance on edge (not applicable to center-point path machining
operations) (not for chamfer)
mm
A
pproach
mode
Quadrant: Part of a spiral (only with path milling left and right of the contour)
Semicircle: Part of a spiral (only with path milling left and right of the contour)
Linear: Slope in space
Perpendicular: Perpendicular to the path (only with path milling on the center path)
A
pproach
strategy
planar
three-dimensionally (not with perpendicular approach mode)
R1 or L1
A
pproach radius (only for path milling on left and right of contour), approach length mm
Retract mode Quadrant: Part of a spiral (only with path milling left and right of the contour)
Semicircle: Part of a spiral (only with path milling left and right of the contour)
Linear: Slope in space
Perpendicular: Perpendicular to the path (only with path milling on the center path)
Retract
strategy
planar
spatial (not with perpendicular approach mode)
R2 or L2 Retract radius (only for path milling on left and right of contour), retract length mm
Retraction
mode
If more than one depth infeed is necessary, specify the retraction height to which the
tool retracts between the separate infeeds (in the transition from the end of the
contour to the beginning).
Z0 + safety clearance
Safety clearance
To retraction plane
No retraction
