10.04 Programming with ShopMill
3.7 Drillin
g
3
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 3-249
Parameters Description
(with A/ or B axis support)
Unit
Z0 Height of workpiece (abs. or inc.) mm
XA: (B can be used everywhere instead of A; Y can be used instead of X)
X0
A
0
1. position of the hole in X (abs. or inc.)
1. position of the hole in A (abs.)
mm
Degr.
X1 ... X8
A
1 ... A8
Other positions in the X axis (abs. or inc.)
Other positions in the A axis (abs. or inc.)
If you want to program further positions, store the ones you have already
programmed and then open the parameter input form again by pressing softkey "Any
positions".
mm
Degr.
XYA: (B can be used everywhere instead of A)
X0
Y0
A
0
1. position of the hole in X (abs. or inc.)
1. position of the hole in Y (abs. or inc.)
1. position of the hole in A (abs.)
mm
mm
Degr.
X1 ... X5
Y1 ... Y5
A
1 ... A5
Other positions in the X axis (abs. or inc.)
Other positions in the Y axis (abs. or inc.)
Other positions in the A axis (abs. or inc.)
If you want to program further positions, store the ones you have already
programmed and then open the parameter input form again by pressing softkey "Any
positions".
mm
mm
Degr.
