Siemens SINUMERIK 810D Operation/Programming

3
10.04 Programming with ShopMill
3.10 Miscellaneous functions
3
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 3-313
3.10.8 Miscellaneous functions
You can e.g. position the spindle again between the individual
machining steps or activate the coolant or stop machining.
The following functions are available:
• Spindle
Determine direction of spindle rotation or spindle position (see
Sec. "Starting, stopping, and positioning a spindle manually")
• Gear stage
Set gear stage, if machine has gears
Please refer to the machine manufacturer's instructions.
• Miscellaneous M functions
Machine functions, such as "Close door"; they are additionally
provided by the machine manufacturer
Please refer to the machine manufacturer's instructions.
• Coolant
Activate/deactivate coolant 1/2
• Tool-spec. fct 1 to 4
Select tool-specific functions 1 to 4; they are additionally provided
by the machine manufacturer
Please refer to the machine manufacturer's instructions.
• Dwell time
Set time after which execution on the machine is continued
• Programmed stop
Stop execution on the machine if the "Programmed Stop" softkey
is also active (see Sec. "Program control").
• Stop
Stop execution on the machine
Machine
funct. >
 Press the "Line Circle" and "Machine func." softkeys.
 Enter the desired parameters.
 Press the "Accept" softkey.
