4
Programming with G Code 10.04
4.1 Creatin
g
a G code
p
ro
g
ram
4
 Siemens AG, 2004. All rights reserved
4-320 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
 Position the cursor on a cycle in the G code editor if you want to
display the associated parameter screen form again.
Recompile
 Select the "Recompile" softkey.
The parameter screen for the selected cycle appears.
Select the "Edit" softkey if you want to go directly back to the G code
editor from a parameter screen form.
Measuring cycle support
 Switch to the extended horizontal softkey bar.
Measure
mill
 Press the "Measure mill" softkey.
Calibr.
probe
...
 Select the required measuring cycle via the softkey.
 Enter the parameters.
OK
 Press the "OK" softkey.
The measuring cycle is transferred to the editor as G code.
 Position the cursor on a measuring cycle in the G code editor, if
you want to display the associated parameter screen form again.
Recompile
 Select the "Recompile" softkey.
The parameter screen for the selected measuring cycle appears.
Select the "Edit" softkey if you want to return directly to the G code
editor from a parameter screen form.
Online help (PCU 50)
 Place the cursor on a G code command in the G code editor or on
an input field in a cycle support parameter screen form.
 Press the "Help" key.
The relevant help screen is displayed.
