4
Programming with G Code 10.04
4.2 Runnin
a G code
ro
ram
4
ï›™ Siemens AG, 2004. All rights reserved
4-322 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
Running a G code
program
-or-
îš¾ Press the "Program" softkey or the "Program Manager" key.
-and-
îš¾ Position the cursor on the desired G code program.
-and-
Execute
îš¾ Press the "Execute" softkey.
-or-
îš¾ Press the "Execute" softkey if you are in the "Program" operating
area.
ShopMill automatically changes to "Machine Auto" operating mode
and loads the G code program.
Cycle Start
îš¾ Press the "Cycle Start" key.
Execution of the G code program starts on the machine.
