6
File Management 10.04
6.2 Pro
g
ram mana
g
ement with PCU 20
6
ï›™ Siemens AG, 2004. All rights reserved
6-354 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
OK
îš¾ Press the "OK" softkey.
A list is displayed in which the different programs must be assigned to
the work offsets. Not all work offsets, i.e. clampings, must be assigned
to programs, but at least two.
Program
selection
îš¾ Press the "Program selection" softkey.
The program overview is displayed.
îš¾ Place the cursor on the required program.
OK
îš¾ Press the "OK" softkey.
The program is included in the assignment list.
îš¾ Repeat this process until a program is assigned to every required
work offset.
On all
clampings
îš¾ If you wish to execute the same program on all clampings, select
"On all clampings" softkey.
You can assign different programs to individual work offsets first,
and then assign one program to the remaining work offsets by
selecting the "On all clampings" softkey.
Delete
selection
Delete all
îš¾ Press the "Delete selection" or "Delete all" softkey if you want to
clear individual or all programs from the assignment list.
Calculate
program
îš¾ Press the "Calculate program" softkey when the assignment list is
complete.
This optimizes the tool changes.
The global program is then renumbered. The number of the current
clamping is specified every time the program switches from one
clamping to another.
Apart from the global program (XYZ.MPF), the file XYZ_MCD.INI is
also set up in which the assignment between work offsets and
programs is stored. Both programs are stored in the directory that was
previously selected in the Program Manager.
If you switch from the assignment list (without "Abort" or "Create
program") to another function and then call the "Multiple clamping"
function later on, the same assignment list is displayed again.
