10.04 Alarms and Messages
8.1 C
y
cle alarms and messa
g
es
8
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 8-401
61203 "Not a position cycle" Program positioning block.
61204 "Unknown technology cycle" Delete and reprogram technology block.
61205 "Unknown position cycle" Delete and reprogram positioning block.
61210 "Block search element not found" Repeat block search.
61212 "Incorrect tool type" Select a new tool type.
61213 "Circle radius too small" Enter a larger value for the circle radius.
61214 "No pitch programmed" The pitch must be programmed
61215 "Blank dimension incorrectly
programmed"
Check dimensions of blank spigot. The blank
spigot must be larger than the finished spigot.
61216 "Feed/tooth possible only for
milling tools"
Alternatively, you can set another feed type
61217 "Cutting rate programmed for tool
radius 0"
Enter a cutting rate setting.
61218 "Feed/tooth programmed, but
number of teeth is zero"
Enter the number of teeth of the cutting tool in
the "Tool list" menu.
61222 "Plane infeed greater than tool
diameter"
Reduce plane infeed.
61223 "Approach path too small" Enter a larger value for the approach path.
61224 "Retract path too small" Enter a larger value for the retract path.
61225 "Swiveling data block unknown" An attempt was made to access a swivel data
block which has not been defined.
61226 "Swivel head cannot be replaced" The parameter "Swivel data block" is set to
"No". In spite of this, an attempt has been made
to change the swivel head.
61230 "Tool probe diameter too small" The tool probe is not correctly calibrated.
61231 "Sequential control program
cannot be executed; not yet tested
by ShopMill"
The program has to be simulated first in
ShopMill or loaded into the operating mode
"Machine auto" by ShopMill.
61232 "Magazine tool cannot be loaded" Only manual tools may be loaded into a swivel
head in which the tools can only be manually
loaded.
61234 "ShopMill subroutine cannot be
executed; not yet tested by
ShopMill"
The subroutine has to be simulated first in
ShopMill or loaded into the ShopMill operating
mode "Machine auto".
61301 "Probe is not responding"
• Check probe connection
• Set a longer measuring distance via
MD 9752, 9753, 9754, 9755
• For edge measurements: Position probe
closer to edge
• For spigots/holes: Position roughly over the
middle
• Check value for spigot/hole diameter
