SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 9-417
Examples
9.1 Example 1: Machining with rectang./circ. pocket and circumf. slot ........................ 9-418
9.2 Example 2: Translation and mirroring of a contour................................................. 9-426
9.3 Example 3: Cylinder surface transformation........................................................... 9-429
9.4 Example 4: Slot side compensation........................................................................ 9-433
9.5 Example 5: Swiveling.............................................................................................. 9-437
